MAIN DIMENSIONS
 Lengthoverall           10.85 m
Breadthoverall         3.85 m
Moulded draft           0.50 m
Displacement            7.00 t
PROPULSION
MainEngines              1 x CUMMINS QSB 6.7; 313kW@3000 rpm
Propellers                    1 x 4 blade (fixedpitch)
LOAD CAPACITY
Passengers                  12
Deadweight                2.5 t
Maximumload           5.0 t
SERVICE PERFORMANCE
 Top Speed                 @100 RPM   30knots
CruisingSpeed        @90 RPM     24knots
Range                            200 NM
CONSTRUCTION
Plates/profiles          5083/6082                series aluminium alloy
CLASSIFICATION
Design category     „B“-OFFSHORE
CAPACITY ARRANGEMENT
 Fuel tank                    600 litres
Fresh water tank   100 litres
Black water tank    100 litres
 HULL SHAPE
 Deep-V planing-AIR STEP HULL
NAVAL ARCHITECTURE
OMNIMONT d.o.o.
DESIGN
Bilus Yacht Design
TYPE AND ASSIGNMENT OF THE BOAT
Working boat –The hul lof the boat has modern deep V form which enables the maintaining of speed and navigation under unfavourable weather conditions.
