Basadura C45

MAIN DIMENSIONS
Lengthoverall                      15.85 m
Breadthoverall                    4.85 m
Moulded draft                      0.70 m
Displacement                      18.00 t
PROPULSION
MainEngines                       1 x CUMMINS QSC 8.3; 442kW@3000 rpm
Propellers                             1 x 4 blade (fixedpitch)
LOAD CAPACITY
Passengers                          12
Deadweight                        2.5 t
Maximumload                   5.0 t
SERVICE PERFORMANCE
Top Speed                              @100 RPM   23knots
CruisingSpeed                    @90 RPM     20knots
Range                                        200 NM
CONSTRUCTION
Plates/profiles                       5083/6082                series aluminium alloy
CLASSIFICATION
Design category                   „B“-OFFSHORE
CAPACITY ARRANGEMENT
Fuel tank                                      600 litres
Fresh water tank                    500 litres
Black water tank                     400 litres
HULL SHAPE
Deep-V planing-AIR STEP HULL
NAVAL ARCHITECTURE
OMNIMONT d.o.o.
DESIGN
Bilus Yacht Design
TYPE AND ASSIGNMENT OF THE BOAT
Luxury Yacht  for personal use- The hull of the boat has modern deep V form which enables the maintaining of speed and navigation under unfavourable weather conditions.
