MAIN DIMENSIONS
Lengthoverall                      17.50 m
Breadthoverall                     05.80 m
Moulded draft                      1.30 m
Displacement                      35.00 t
PROPULSION
MainEngines                       2 x CUMMINS QSK; 600kW@1800 rpm
Propellers                             2 x 4 blade (fixedpitch)

LOAD CAPACITY
Passengers                          12 (6 crew+ 6 passengeres)
Deadweight                        10 t
Maximumload                    10 t

SERVICE PERFORMANCE
Top Speed                              @100 RPM   30.0knots
Working Speed                   @90 RPM     25.0knots
Range                                        300 NM

CONSTRUCTION
Plates/profiles                       5083/6082                (Options: STEEL)

CLASSIFICATION
CRS/LR                                       90A13/M1AUT3

CAPACITY ARRANGEMENT
Fuel tank                                    4000 litres
Fresh water tank                   500 litres
Black water tank                    500 litres

HULL SHAPE
Deep-V planing-AIR STEP HULL

NAVAL ARCHITECTURE
OMNIMONT d.o.o.

DESIGN
Bilus Yacht Design

TYPE AND ASSIGNMENT OF THE SHIP

Multi role patrol vessel designed for the coast guard but can be also adapted to other general police or military dutie
