MAIN DIMENSIONS

 Length overall                     13.0 m
Breadth overall                    04.00 m
Moulded draft                      0.70 m
Displacement                      11.00 t

PROPULSION
Main Engines                      1 x CUMMINS QSB 6.7; 313kW@3000 rpm
Propellers                             1 x 4 blade (fixed pitch)

LOAD CAPACITY
Passengers                          12
Deadweight                        2.5 t
Maximum load                   5.0 t

SERVICE PERFORMANCE
Top Speed                              @100 RPM   28 knots
 Cruising  Speed                    @90 RPM     25 knots
Range                                          250 NM

CONSTRUCTION
Plates/profiles                         083/6082                series aluminium alloy

CLASSIFICATION
Design category                        B“-OFFSHORE

CAPACITY ARRANGEMENT
Fuel tank                                        2000 litres
Fresh water tank                       300 litres
Black water tank                      300 litres

HULL SHAPE
Deep-V planing-AIR STEP HULL

NAVAL ARCHITECTURE
OMNIMONT d.o.o.
DESIGN
Bilus Yacht Design

TYPE AND ASSIGNMENT OF THE BOAT

Offshore pilot boat designed for the raiding but can be also adapted to other general police or military duties
